MACHINING PERFORMANCE
Turning Capability
| Test Model | Work-piece | Cutting Condition | Power Requirement | ||||
|---|---|---|---|---|---|---|---|
| GLS-1500 | Material | Diameter ( mm ) |
Spindle Speed ( rpm ) |
Cutting Speed ( m/min. ) |
Cutting Depth ( mm ) |
Feedrate ( mm/rev. ) |
Spindle Load ( % ) |
| Heavy Cutting | S45C | Ø 50 | 1,050 | 165 | 4 | 0.25 | 126 / 38 |
| Drill | S45C | Ø 40 | 954 | 120 | — | 0.13 | — |
Machining Capability
| Test Model | Work-piece | Cutting Condition | Power Requirement | ||||
|---|---|---|---|---|---|---|---|
| GLS-1500M | Material | Diameter ( mm ) |
Spindle Speed ( rpm ) |
Cutting Speed ( m/min. ) |
Cutting Depth ( mm ) |
Feedrate ( mm/min. ) |
Spindle Load ( % ) |
| Drill | S45C | Ø 13 | 610 | 25 | — | 183 | 120 / 80 |
| End Mill | S45C | Ø 13 | 490 | 30 | 15 | 122 | 180 / 30 |
| Tapping | S45C | M12 x P1.75 | 400 | 15 | — | 700 | 200 / 27 |
